pivot system in SS304 (available also in SS316) double action for doors up to 200kgs made in Portugal.

pivot system in metal (available also in stainless steel) double action for doors up to 150kgs made in UK.

pivot system in metal (available also in stainless steel) double action for doors up to 300kgs made in UK.

pivot system in SS304 (available also in SS316) double or single action for doors up to 65kgs made in Portugal.

hydraulic pivot system double or single action with 90º stop for doors up to 100kgs with a minimum door panel thickness of 40 mm available in Matt Black, Matt Gold, Copper, Stainless Steel and Chrome made in Portugal.

hydraulic pivot system double or single action in SS304 with 90º stop for doors up to 200kgs tested to EN1154 with 5 fixed power with a minimum door panel thickness of 50 mm made in Portugal.

hydraulic pivot system double or single action CAM action in SS304 with 90º stop for doors up to 200kgs tested to EN1154 with 5 fixed power with a minimum door panel thickness of 50 mm made in Portugal.

hydraulic pivot system double or single action CAM action in SS304 with 90º stop for doors up to 350kgs tested to EN1154 with 2-4 power with a minimum door panel thickness of 50 mm made in Portugal.

hydraulic pivot system double or single action CAM action in SS304 with 90º stop for doors up to 500kgs tested to EN1154 with 3-5 power with a minimum door panel thickness of 60 mm made in Portugal.

hydraulic pivot system double or single action CAM action in SS304 with 90º stop for doors up to 1000kgs tested to EN1154 with 3-6 power with a minimum door panel thickness of 70 mm made in Portugal.

hydraulic pivot system double or single action with upper and lower adjustable hinges. Plate to mount to floor is fixed for doors up to 500kgs with 90º stop made in Italy.

hydraulic pivot system double or single action with upper adjustable hinge, lower hinge and adjustable plate to floor. For doors up to 500kgs made in Italy.

hydraulic pivot system double or single action with upper adjustable hinge and lower hinge with stopping every 90º. Plate to mount to floor is fixed for doors up to 500kgs with 90º stop made in Italy.

hydraulic pivot system double or single action with upper adjustable hinge and lower hinge with stopping every 90º. Lower hinge has 3 different stop forces. Plate to mount to floor is fixed for doors up to 500kgs with 90º stop and 20º return before stopping made in Italy.

hydraulic pivot system with fixed force (EN 3). Hold-open version (which, in addition to closing the door, allows it to be locked at 90 degrees) for doors up to 100kgs and maximum width of 950mm made in Italy.

hydraulic pivot system with fixed force (EN 5). Hold-open version (which, in addition to closing the door, allows it to be locked at 90 degrees) tested to EN 1154 for doors up to 100kgs and maximum width of 1250mm made in Italy.
